Motorcycle Ignition Coil
| Ignition Coil Technical Specifications | |||
| Primary Winding Material | Pure Copper Enameled Wire (Class H) | Secondary Winding Material | Pure Copper Enameled Wire (Fine Wire) |
| Core Material | Silicon Steel Laminations (0.35mm / 0.5mm) | Housing Material | PBT / PA66 (Flame-Retardant, UV Resistant) |
| Encapsulation Material | Epoxy Resin (Vacuum Potting) | Primary Resistance | 0.5 – 5.0 Ω (depending on model) |
| Secondary Resistance | 6 – 20 kΩ (depending on model) | Output Voltage (Max) | 20 – 40 kV |
| Spark Energy | 50 – 150 mJ | Dwell Time | 1.5 – 4.0 ms (CDI/DC-CDI compatible) |
| Input Voltage | 6V / 12V DC (depending on model) | Ignition Type | CDI / DC-CDI / Transistorized (TCI) |
| Connector Type | Faston / Molex / Amp / Custom | Mounting Type | Screw mount / Rubber grommet / Bracket |
| Insulation Resistance | ≥ 100 MΩ @ 500 VDC | Dielectric Strength | ≥ 30 kV (no breakdown) |
| Operating Temperature Range | -30°C ～ +120°C | Storage Temperature | -40°C ～ +130°C |
| Ingress Protection (IP Rating) | IP54 / IP65 (optional) | Vibration Resistance | 10 – 500 Hz, 5G |
| Quality Certification | ISO 9001:2015 | Warranty | 12 months |
| Origin | China | ||
